Yamaha receivers don't use a big numbered fault system — they show short on-screen messages or signal a problem by shutting down. Here's what the common ones mean and how to fix each, grouped by where the trouble actually is.
"CHECK SP WIRES" / it shuts off (protection mode)
The receiver sensed a short on the speaker outputs and went into protect mode. Almost always a stray strand of speaker wire bridging the terminals, sometimes overheating.
- Unplug and check every speaker terminal for stray strands; re-strip and re-seat each wire.
- Test with all speakers disconnected — if it powers up and stays on, reconnect one at a time to find the bad cable. If it trips bare, it's internal.
- Check impedance — speakers below the receiver's rating (set the low-impedance mode for 4Ω) overdraw the amp.
- If it only trips when hot, improve ventilation and let it fully cool.
The full CHECK SP WIRES / protect mode walkthrough covers how to isolate which speaker cable is shorting.
It won't turn on / blinks standby
Usually a stuck power state. Power-drain it: unplug from the wall, hold the power button 30 seconds, plug into a known-good outlet, and try again. If that fails, do a microprocessor reset per your model's manual. A completely dead unit after that is likely a power-supply fault. (See Yamaha won't turn on for the step-by-step power-drain.)
No picture / "No Signal" over HDMI
An HDMI handshake or passthrough problem. Confirm the input assignment, reseat and swap the cable for a certified one, set the power-on order (source → receiver → TV), and update the firmware. Test the source straight to the TV to isolate it. (Note: some older Yamaha models have a known HDMI-board weakness — if HDMI video dies progressively while audio still works, that's a board fault, not your cable.)
No sound (everything connected)
Check the input's audio assignment, that it's not on a Pure Direct/silent mode, and the speaker configuration. For TV audio over ARC, enable HDMI Control (CEC), set ARC On in the HDMI menu, and switch the TV's audio output to the receiver — the eARC/ARC not working with TV apps guide has the full order plus the eARC-vs-ARC catch.
Network / streaming errors
The receiver can't reach the internet or a service. Reboot the router and receiver, re-run network setup, set a public DNS at the router (8.8.8.8), and update firmware. Wired Ethernet beats Wi-Fi for AV receivers, and the MusicCast app is a handy alternative controller while you sort it out.
FAQ
What does CHECK SP WIRES mean? A speaker-output short tripped protection mode. Disconnect all speakers and power on; if it stays on, reconnect one at a time to find the short.
My Yamaha won't turn on. Power-drain it: unplug, hold the power button 30 seconds, plug into a known-good outlet. Then a microprocessor reset if needed.
No picture through the receiver. An HDMI handshake issue — check the input assignment, reseat/swap the cable, and power on source → receiver → TV. Progressive HDMI failure on older models is a board fault.
No sound but I have a picture. Check the input's audio assignment and listening mode; for TV audio, enable HDMI Control/ARC and set the TV output to the receiver.
